G100 Sling Hook Eye w/Latch Yoke
Price range: $19.00 through $38.00
Heavy-duty Grade 100 swivel ball bearing self-locking hook, designed to reduce sling twist and enable rotation under load.
Description
The G100 Sling Hook Eye w/Latch Yoke is engineered for superior lifting performance, featuring at least 25% greater WLL than traditional G80 products. Manufactured from quenched and tempered alloy steel, this hook ensures maximum safety, durability, and fatigue resistance, making it ideal for high-demand lifting operations.
Certified in accordance with EN 1677-2, ASME B30.26, ASME B30.10, and PAS1061, each hook is proof load tested at 2.5× WLL, providing industry-compliant strength. It has a design factor of 4:1, is fatigue rated for 20,000 cycles at 1.5× WLL, and undergoes Magnaflux crack detection on 100% of each batch, guaranteeing high-quality assurance.
Advantages:
- 25% greater WLL than G80 hooks
- Latch mechanism for secure load handling
- Certified to multiple industry standards
- Batch tested for reliability
- Fatigue rated for durability
What’s Included:
- 1 x G100 Sling Hook Eye w/Latch Yoke (As per size selected)
Additional information
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Size | 6mm, 8mm, 10mm |
