Swivel Lifting Point Long Thread with Nut
6055xx1_4zopjkbu.e5q
Swivel Lifting Point Long Thread with Nut
Icons / Feature / Tracked Parcels

Special Ordered Items have extended Delivery or Click & Collect timelines. Please purchase and we will organise the goods for you. Read More

SLPYLN

Swivel Lifting Point Long Thread with Nut

$62.00 – $156.00

Swivel lifting point with extended thread length and nut, featuring 360-degree rotation and 180-degree pivot, manufactured from forged alloy steel, tested to EN1677-1 standards.

SLPYLN0.3T
SLPYLN0.63T
SLPYLN1T
SLPYLN1.2T
SLPYLN1.5T
SLPYLN2T
SLPYLN2.5T
Make an Enquiry
Delivery Quote

SKU: SLPYLN Category:
  • Description

    The Swivel Lifting Point Long Thread with Nut is designed for secure and multidirectional load handling, featuring 360-degree swivel rotation and 180-degree pivot functionality for precise lifting. Manufactured from forged alloy steel, quenched and tempered, it meets EN1677-1 safety standards and undergoes rigorous testing, including proof load testing, break testing, and magnaflux crack detection. The smooth galvanized anchor bolt enhances corrosion resistance, while the internal retention spring allows for pre-load positioning to prevent twisting and binding. The long factory full-thread bolt provides customized thread length options, improving adaptability across industries.

    Advantages:

    • 360° rotation
    • 180° pivot
    • Forged alloy steel
    • Includes nut
    • Extended thread length
    • Corrosion-resistant finish



    What’s Included:

    • 1 x Swivel Lifting Point Long Thread with Nut (Size as selected)
  • Features
    • 360-degree swivel rotation and 180-degree pivot enable precise multidirectional lifting with maximum flexibility.
    • Forged alloy steel construction, quenched and tempered, ensures durability and enhanced load-bearing capacity.
    • Includes nut for secure fastening, improving stability and load efficiency during lifting operations.
  • Specifications
    Standard
    EN1677-1, ASME B30.26
    Thread Type
    Metric thread (ASME / ANSI B18.3.1M)
    Testing
    Proof tested at 2.5 times WLL
    Fatigue Rating
    1.5 times WLL
    Material Inspection
    100% magnaflux crack detected
    Traceability
    Individual forged parts batch-coded
    Installation
    Requires a tapped hole for quick and simple assembly
    Corrosion Resistance
    Smooth galvanized anchor bolt prevents rust fatigue

Description

The Swivel Lifting Point Long Thread with Nut is designed for secure and multidirectional load handling, featuring 360-degree swivel rotation and 180-degree pivot functionality for precise lifting. Manufactured from forged alloy steel, quenched and tempered, it meets EN1677-1 safety standards and undergoes rigorous testing, including proof load testing, break testing, and magnaflux crack detection. The smooth galvanized anchor bolt enhances corrosion resistance, while the internal retention spring allows for pre-load positioning to prevent twisting and binding. The long factory full-thread bolt provides customized thread length options, improving adaptability across industries.

Advantages:

  • 360° rotation
  • 180° pivot
  • Forged alloy steel
  • Includes nut
  • Extended thread length
  • Corrosion-resistant finish



What’s Included:

  • 1 x Swivel Lifting Point Long Thread with Nut (Size as selected)

Additional information

Weight N/A
Dimensions N/A
Size

8mm, 10mm, 12mm, 14mm, 16mm, 18mm, 20mm
